Place of Origin: | Guangzhou |
Brand Name: | XF-STAR |
Certification: | TUV and SGS |
Minimum Order Quantity: | 10/Meters |
---|---|
Price: | USD/40-70/Meter |
Packaging Details: | ir bubble film that could be suitable for long transport |
Delivery Time: | 5-7 days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 1000/Meters/week |
Main Tube: | 50*3.0mm | Brace: | 25*2mm |
---|---|---|---|
Size: | From 600*760mm To 200*200mm | Shape: | Square |
Certificate: | TUV And SGS | Fuction: | Exhibiton Truss |
High Light: | circular lighting truss,stage lighting truss systems |
Silver Square 5 Stars Stage Lighting Truss 300 x 300 For Performance
Specification
Size(mm)
|
Main Tube(mm) | Horizontal tube(mm) | Brace Tube(mm) | Loading Capacity(kg) | Span(m) |
300*300 | 50*3 | 30*2 | 25*2 | 300 | 12 |
350*350 | 50*3 | 30*2 | 25*2 | 500 | 14 |
400*400 | 50*3 | 50*2 | 25*2 | 600 | 16 |
450*450 | 50*3 | 50*2 | 25*2 | 700 | 18 |
500*500 | 50*3 | 50*2 | 25*2 | 700 | 20 |
520*760 | 50*3 | 50*2 | 25*2 | 1000 | 22 |
600*760 | 50*3 | 50*2 | 25*2 | 1500 |
26
|
Material analysis
Material |
Aluminum 6082/T6. Aluminum 6061/T6 |
Length available |
1m,2m,3m,4m. OEM offered. |
Shape |
Ladder,Triangle,Square,Circle Truss |
Color |
Silvery and black or customized |
Type |
Spigot and screw |
Certification |
TUV,SGS |
Characteristics |
Durable,Light Weight with high loading capacity.Raw material is aprecipitation hardening aluminum alloy, Containing magnesium and silicon as its major alloying elements. It has good mechanical properites, exhibits good weldability. It also has good effect of Proof Stress, corrosion resistance, antioxidation. |
application |
LED truss to hang LED screen / Iinear speakers or decorate truss |
Background truss: to hang up lights and LED, screen for truss frame |
|
Truss system: to hold events( for light, LED, speaker, audio, and so on) |
|
Layder truess: hanging speakers |
